A36 Round Steel Bar

A36 is a low-carbon steel containing manganese, phosphorus, sulfur, silicon and copper. A36 has good weldability and high yield strength. A36 carbon steel bar is commonly used as a variety of structural steel parts.

Classification :

Carbon Steel Bar

+8613581707776

Cowin@sdsilkroadsteel.com

E-mail

PRODUCT DETAILS

A36 Round Steel Bar Description

A36 is a carbon structural steel whose chemical composition and mechanical properties strictly conform to American ASTM standards. A36 steel bar mainly consists of iron, carbon, silicon, manganese, phosphorus, sulfur and other elements. Iron constitutes more than 99% of the entire chemical composition. Its carbon content proportion is relatively high, around 0.2%, ensuring that the steel has a certain hardness and toughness. The addition of silicon, manganese and other elements enhances the strength and toughness of steel. Phosphorus and sulfur are low so that the steel bar has good welding performance and corrosion resistance. A36 steel bar is used for welded, bolted or riveted construction of bridges and buildings, as well as for general structural purposes. Due to its lowest yield point, A36 can be used to design lighter-weight structures and equipment, and provide good weldability.

Product Parameters

Product Name	A36 Round Steel Bar
Standard	EN/DIN/JIS/ASTM/BS/ASME/AISI, etc.
Common Round Bar Specifications	3.0-50.8 mm, Over 50.8-300mm
Flat Steel Common Specifications	6.35x12.7mm, 6.35x25.4mm, 12.7x25.4mm
Hexagon Bar Common Specifications	AF5.8mm-17mm
Square Bar Common Specifications	AF2mm-14mm, AF6.35mm, 9.5mm, 12.7mm, 15.98mm, 19.0mm, 25.4mm
Length	1-6meters, Size Accept Custom
Diameter(mm)	Hot Rolling Round Bar	25-600	Cold Rolling Square Bar	6-50.8
	Hot Rolling Square Bar	21-54	Cold Rolling Hexagon Bar	9.5-65
	Cold Rolling Round bar	6-101.6	Forged Rebar	200-1000
Surface Process	Bright, Polished, Black
Other Services	Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.

Chemical Composition

C	Cu	Fe	Mn	P	Si	S
0.25～0.290	0.20	98.0	1.03	0.040	0.280	0.050

Mechanical Properties

A36	Limit Tensile Strength	Tensile Strength, Yield Strength	Elongation at Break(Unit: 200mm)	Elongation at Break(Unit: 50mm)	Modulus of Elasticity	Bulk Modulus(Typical for Steel)	Poisson's Ratio	Shear Modulus
Metric	400～550MPa	250MPa	20.0%	23.0%	200GPa	140GPa	0.260	79.3GPa
Imperial	58000～79800psi	36300psi	20.0%	23.0%	29000ksi	20300ksi	0.260	11500ksi

Physical Performance

Physical Performance	Metric	Imperial
Density	7.85 g/cm3	0.284 lb/in3

Scope of Application

Bolted, riveted or welded structures for bridges, buildings and oil drilling rigs.
Used for forming storage tanks, silos, bearing plates, fixtures, rings, templates, fixtures, sprockets, cams, gears, bottom plates, forgings, decoration engineering, piles, brackets, automobiles and agricultural equipment, frames, mechanical parts, etc.

Equivalent Material

National Standard GB	European Standard EN	American Standard ASTM	German Standard DIN,WNr	Japanese Standard JIS	French Standard AFNOR	British Standard BS	Canada HG
Q235B	S235JR	A283C	St37-2	SM400A	E24-2	40A/40B	230G
Italy UNI	India IS	Switzerland SS	Australia ONORM	Norway NS	Spain UNE	International Standards ISO	Portugal NP
Fe360B	IS2062	1311/1312	RSt360B	NS12123	AE235B-FN	E235B/Fe360B	FE360-B

ROUND BAR SIZE

Size in mm	Average Weight
Size in mm	KG/MTR	KG/FT
10	0.62	0.18
12	0.90	0.30
14	1.20	0.40
16	1.60	0.50
18	2.00	0.60
20	2.50	0.80
22	3.00	0.90
24	3.56	1.08
25	3.90	1.20
28	4.80	1.50
30	5.55	1.69
32	6.30	1.90
34	7.14	2.18
36	8.00	2.44
40	9.90	3.00
45	12.49	3.81
50	15.40	4.70
56	19.34	5.89
60	22.20	6.80
63	24.47	7.46
63.5	24.86	7.58
65	26.05	7.94
70	30.20	9.20
73	32.86	10.00
75	34.72	10.58
78	37.51	11.43
80	39.50	12.00
83	42.47	12.95
85	44.55	13.58
90	50.00	15.20
92	52.19	15.91
93	53.39	16.27
95	55.65	16.95
100	61.66	18.79
105	67.98	20.72
110	74.60	22.74
115	81.64	24.88
125	96.34	29.36

PACKING AND SHIPPING

We have our own transportation fleet with the most convenient transportation and timely delivery.The company's products are exported to more than 70 countries and regions in the world, including Europe, America, Germany, South Korea, Indonesia, Bangladesh, etc.

FACTORY WORKSHOP

We are a steel manufacturer with a long history and reputation for excellence. Since our establishment in 2018, we have always been committed to providing customers with the highest quality and most efficient steel products and steel deep processing services to meet their needs in various engineering projects.

CUSTOMER VISIT

In the future development, we will continue to uphold the concepts of professionalism, integrity, innovation and unity, continuously improve product quality and service levels, and provide customers with more high-quality and efficient steel products and services. We look forward to working with you to create a better future!

APPLICATION AREAS

Our product range covers various specifications of steel plates, steel sections, steel pipes, etc., which are widely used in construction, bridges, machinery, ships, oil, natural gas, and other fields. We always adhere to strict quality management to ensure that every product meets national standards and customer requirements.

FAQ

Q1:Can you send samples?

A:Of course, we can provide customers with free samples and express shipping service to all over of the world.

Q2:What product information do I need to provide?

A:Please kindly provide the grade, width, thickness, surface treatment requirement should you have and quantities you need to purchase.

Q3:It's my first time to import steel products, can you help me with it?

A:Sure,we have agent to arrange the shipment, we will do it together with you.

Q4:What about product prices information?

A:Prices various according to periodic price changes of raw materials.

Q5:What ports of shipment are there?

A:Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you can specify other ports according to your needs.

Q6:What is your terms of payment ?

A:Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment or based on BL copy or LC at sight.
